TGE 5, TGE 5-Ex, TGM 5, TGM 5-Ex, TGU 5, TGU 5-Ex Transmitter for angular position ABB

TGE 5, TGE 5-Ex, TGM 5, TGM 5-Ex, TGU 5, TGU 5-Ex Transmitter for angular position ABB

Conversion of the angular position of the shafts of
mechanical primary detectors into a load-independent
direct current signal
High precision
— Non-linearity < 1 %
Simple conversion from 2, 3 or 4-wire operation
(only 2-wire circuit in the case of devices with
explosion protection)
Options
— Electrical isolation between output and power supply
— Marine version with German Lloyd approval
— Intrinsically safe version for operation in Zone 1
— Limitation of superimposed interference voltage peaks
— Plug connection Han 7 D

Version TGE 5, TGE 5-Ex for attachment to
— Pressure gauges (with mounting hardware)
— Scales etc.
Version TGM 5, TGM 5-Ex for attachment to shafts
— In heavy machinery
— On ships etc.
Version TGU 5, TGU 5-Ex for installation in
— Pressure gauges
— Rotameters
Installation in systems with very high mechanical and
climatic stress
The customer’s specific adjustments are effected at the
factory, but can be changed subsequently
